Usage
• Click a field to make or break a route. Large fields are 64x64, medium fields 8x8 and small fields 1x1 channels wide.
Clicking a field routes all contained channels at once in a linear (1:1) fashion.
• Click+drag to make multiple routes. Hold SHIFT to delete multiple routes.
• Click to expand to group/channel levels, to collapse.
• The " Optimal" button adjusts the view which makes all sub-routings visible.
How to use
The list on the left contains all currently defined routes, in the format described below.
To add a route, click and enter the route accordingly
To change a route, select it from the list and click on
To remove a route, select it from the list and click on
Sources and sinks can be specified as follows:
Entire interfaces (all 64 channels) as abbreviation: AD, MO, MC, MT, AE, DA, FLX1, FLX2, FLX3 (for ADAT, MADI optical, MADI coaxial, MADI-TP, AES50, Dante or FlexLink)
Subrange (1-64 channels on a particular interface) interface:start-end E.g. MADI optical, channels 9-16 will be written as MO:9-16
Single channel a particular interface: interface:ch E.g. Dante, channel 22 will be written as DA:22
Routes can be given as either "Source > Sink", or "Sink < Source":
MO > DA routes all 64 channels from MADI optical to Dante
MC:4 > AE:8 routes channel 1 from MADI coaxial to AES50, channel 8
AD:1-8 < AE:41-48 makes AES50 channels 41-48 appear on ADAT channels 1-8
Notes:
Aggregate interfaces (i.e. MO+MC on the ASRC) are specified only as the first part, e.g. MO,
the second interface (MC) is implicitly added.
A route can also be cleared by specifying NONE as source, i.e. AD < NONE.
Clock A (main clock, for everything except the SRC inputs/outputs)
All I/Os except those selected for SRC use this clock
Unknown
Clock B (alternate clock for input/outputs routed through SRC)
Enables selected inputs and/or outputs to run on a different clock
In most cases, set this to match the first SRC input
Unknown
Monitor (Headphones)
Input interface where the monitor listens to
For stereo monitoring: left channel number
Extra gain can be configured in "Device" tab.
Settings (* indicates default setting, [xx] indicates function number)
Extra gain may cause clipping on large signals! [01]
Output format for MO (input always auto-detected) [02]
Standard MADI (AES10)
Output format for MC (input always auto-detected) [03]
